CCTV Power Supply (Closed) 12V 30A
12V 30A CCTV Power Supply (Closed Metal Box / Enclosure Type)
🔧 Technical Specifications
| Parameter | Details |
|---|---|
| Output Voltage | 12V DC ±5% |
| Output Current | 30 Amps (Max) |
| Total Power | 360 Watts (12V × 30A) |
| Input Voltage | 100–240V AC, 50/60 Hz |
| Design Type | Closed metal box with ventilation holes |
| Number of Outputs | Typically 18 fused DC outputs |
⭐ Key Features
✅ High Power Output
-
Capable of powering 18 to 32 CCTV cameras (depending on power draw per camera).
-
Ideal for installations with IR cameras, PTZs, DVR/NVR systems, microphones, and accessories.
✅ Enclosed Metal Casing
-
Sturdy steel casing with powder coating.
-
Lockable front panel for tamper resistance.
✅ Fused Outputs
-
Each DC output has a dedicated glass fuse or PTC resettable fuse.
-
Helps isolate and protect individual channels in case of a short circuit.
✅ Status Indicators
-
LED indicators for each channel show power status for fast troubleshooting.
✅ Protection Features
-
Overload protection
-
Overvoltage protection
-
Short circuit protection
-
Over-temperature protection (in some models)
✅ Cooling System
-
Ventilation holes or built-in cooling fan (model-dependent) for temperature management.
✅ Easy Mounting
-
Pre-drilled holes for wall or rack mounting.
-
Terminal blocks for simple and secure wiring,
